BS PD ISO/TS 13399-303:2016

Full Description

BS PD ISO/TS 13399-303:2016 specifies a concept for the design of tool items, limited to solid (non-indexable)end mills, with the usage of the related properties and domains of values.

This part of ISO/TS 13399 specifies a common way of design simplified models that contain the following: definitions and identifications of the design features of solid (non-indexable) end mills, with a linkto the properties used; definitions and identifications of the internal structure of the 3D model that represents featuresand properties of solid (non-indexable) end mills.The following are outside the scope of this part of ISO/TS 13399: applications where these standard data may be stored or referenced; creation and exchange of simplified 3D models for cutting tools; creation and exchange of simplified 3D models for cutting items; creation and exchange of simplified 3D models for other tool items not being described in the scopeof this part of ISO/TS 13399; creation and exchange of simplified 3D models for adaptive items; creation and exchange of simplified 3D models for assembly items and auxiliary items.
Cross References:
ISO/TS 13399-3
ISO/TS 13399-4
ISO/TS 13399-60
ISO/TS 13399-80
ISO 13399-1
ISO 13584-24
ISO 13584-25
ISO/TS 13399-2
ISO/TS 13399-5
ISO/TS 13399-50
ISO/TS 13399-70
ISO/TS 13399-100
ISO/TS 13399-150
